Large High Speed 5 Axis Cnc Router for Making Boat Building for Wind Turbine Blade Mold Manufacturing of SF Large Scale Series be designed to meet the produciton needs of the automotive, aeronutical, and marine sectors, and composite components.
Video Show of Custom Made 19 Meter Large Ship Model Machining Equipment
Features and Advantages of Custom Made 19 Meter Large Ship Model Machining Equipment：
1. Large High Speed 5 Axis Cnc Router for Making Boat Building for Wind Turbine Blade Mold Manufacturing of SF Large Scale Series be designed to meet the produciton needs of the automotive, aeronutical, and marine sectors, and composite components.
2. The SF Large Scale Series models with heavy duty stucture for a good performance: high efficiency, short machining times, high quality surface finish, rigidity over time and long life time.
3. Personalized services designed to satisfy different customer demands.
Custom Made 19 Meter Large Ship Model Machining Equipment Industry & Materials:
Technical Parameters of 5 Axis Mold and Sculpture Making:
| Stroke Size(mm) | X:19000 Y:7000 Z:3500 |
| 5 Axis Working Size(mm) | X:18000 Y:6000 Z:3100 |
| Rotary Head | CHENcan Brand |
| Spindle | Italy HITECO 15Kw Spindle |
| Spindle Speed | 24000rpm/min |
| Spindle Cone | HSK 63F |
| A Axis | ±120° |
| C Axis | ±360° |
| Control CNC | HNC |
| Tool Change | 10 Positions |
| Drive Type | X: Incline Rack & Pinion
YZ: High precision ball screws |
| Work Model | AC Servo Drive |
| Max Working Speed X/Y/Z(mm) | 40/40/10 |
| Max Rapid Speed X/Y/Z(m/min) | 60/60/20 |
| Positioning Accuracy X/Y/Z(mm/m) | 0.04/0.04/0.04 |
| Repeatability X/Y/Z(mm/m) | 0.025/0.025/0.025 |
| Work Table type | No Table |
| Air Pressure (kgf/cm2） | ≥0.08 |
| Total Power (KVA) | 42 |
| Gross Weight (T) | 30 |
Optional Configuration of 5 Axis Mold and Sculpture Making:
| Control CNC | Siemens, Syntec |
| Spindle | From 15kw up to 42kw, 24000rpm max. |
| Spindle Head | H Type-Double Shoulder Type |
| Anti-Backlash | For X axis or all axis |
| Work Table | Cast Iron Table, Iron Table, Vacuum Table |
| Around Protection | Enclosure, Roof |
| Dust Suction System | Grids+hood |
| Vision Cameras | 2 cameras, 4 cameras |
| Tool Sensor | TSR27, NC4 |
| Probe | RMP60, RMP600 |
High Accuracy 5 Axis Mold Manufacturer Router project:
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
5 axis mould cnc router is a high-precision and high-efficiency machine. Regular maintenance is important to keep its accuracy and extend its lifetime.
1. Dust Cleaning: Daily clean the work table after one day work, keep the appearance of the surface of the large 5 axis cnc machine, and prevent dust and debris from entering the equipment.
2. Parts Maintenance: Regularly check the various parts of the surface of the large 5 axis cnc machine, including guide rails, transmission systems, spindles, collet, etc., to ensure that they operate normally, and find and solve problems in time.
3. Lubrication Maintenance: large 5 axis cnc machine adopt auto lubricate system, which will lubricate the various parts of the machine according to the requirements automatically, but need to check the oil level in pump regularly.
4. Temperature Control: Regularly check the working temperature of the large 5 axis cnc machine to avoid high temperature affecting the machine’s operation, and handle abnormal temperature problems in time.
5. Regular Calibration: Calibrate the machine regularly to ensure the processing accuracy and stability of the large 5 axis cnc machine.
6. Safety Protection: Ensure the safety protection around the machine are good to ensure the operator safety and avoid accidents.
7. Timely Maintenance: When machine collision or problems are found, please contact the professional maintenance personnel in time for repair to avoid the problem from affecting the normal use of the machine.
In the end, large 5 axis cnc machine require regular maintenance and attention to keep the machine in good condition and improve its accuracy, efficiency and lifetime.
